Union KC-150 HDT CNC Horizontal Boring Mill (2006): 6” spindle, 157” x-axis, 118” y-axis, 98” z-axis, 29” w-axis, 78” x 118” contouring rotary table (44,000 lb load capacity), KFUD3 automatic 1° universal head, automatic head changer, Heidenhain iTNC-530 control, tool changer (60 tools)
_(12).jpg "c6 capto 4 station turret")
Union KCU-150 HDT CNC Horizontal Boring Mill (2008): 6” spindle, 126” x-axis, 118” y-axis, 59” z-axis, 29” w-axis, 79” x 98” contouring rotary table, integrated facing head, Siemens 840D control, and tool changer (60 tools) Union PC-150 CNC Horizontal Boring Mill (2010): 6” diameter spindle 396” x-axis, 138” y-axis, 30” z-axis, 29” w-axis 98” x 98” contouring rotary table, 30-ton capacity, 2.5° automatic indexing head, Heidenhain iTNC-530 control tool changer (40 tools) Ibarmia ZVH58 L4000 5-axis travelling column machining center (2008): 157” X-axis, 39” Y-axis, 34” Z-axis, 6000 RPM continuous tilting head, integrated 39” diameter contouring rotary table, 181” x 41” plain table, Heidenhain iTNC-530 control, automatic tool changer (40-tools) Milling Department (Horizontal Boring Mills)-CNC Trimill VF 10035 5-axis Gantry Mill (2016): 393” X-axis, 138” Y-axis, 59” Z-axis (RAM), 10,000 RPM fork-type milling head F4F, 413” x 149” table, Heidenhain iTNC-530 control, automatic tool changer (30-tools) Siemens 840D Smartline control, Renishaw Tool robe, Renishaw Touch Probe, tool changer (60 tools) 63” Diameter, 300RPM maximum speed rotary table with 17,600 lb load capacity. 84HP main spindle with HSK A-100 spindle taper. Ibarmia THC 1600 Multiprocess (2014): 79” X-axis, 59” Y-axis, 59” Z-axis, 7000 RPM 2-axis continuous milling, drilling, facing, turning & boring head.
(1) steady 15 ¾ - 35 ½ capacity, boring attachment 8” capacity, probing, camera, Siemens 840D control Union PCR-160 RAM Type CNC Horizontal Boring Mill (2011): 17” x 22” RAM, 6 5/16” diameter spindle 590” x-axis, 236” y-axis, 59” z-axis, 29” w-axis CNC right angle head, automatic head changer for heads and turning/facing block, 157” x 157” b-axis rotating and turning table, 118” v-axis infeeding table 120 ton capacity, turning/facing capacity up to 324” dia., Heidenhain iTNC-530 control, tool changer vertical/horizontal (60 tools), 189” x 314” long floor plate field.īOST VTL 60 CY Traveling Table Vertical Turning, Boring and Milling Machine (2012): 236” swing 141” turning height, 79” RAM travel, 157” table diameter with table extensions to 216” diameter 8-jaw, live spindle (3000 RPM), hydraulically clamping right angle milling attachment, 236” x-axis travel, 157” y-axis travel, adjustable cross rail, automatic head changing, Siemens 840D control, automatic tool changer (28-milling, 12-turning)īOST T4F Horizontal Turn/Mill (2012): 79” swing, 354” center distance, 44,000 pound capacity between centers without steady rest, 93 HP turning power, guillotine turning with Capto C6 tooling, 68 HP milling tower, b-axis head +/- 90 degrees, HSK-125 tooling, 60 station ATC, Qty. Milling, Turning, Facing, Drilling, & Boring To view and print a complete list of our Facilities and Equipment, click here.Įquipment Multi-Process and 5-axis Machining (Horizontal/Vertical) Taylor Rigger’s special fork truck with boom
